S Series |
|
Resolution |
4096*4096 |
|
Scan rate（scans/s） |
50scans/s |
|
Transmittance |
>95 last can to 100% |
|
Touch the smallest body |
>5mm |
|
Response speed |
>16ms |
|
Durability |
Bear more than more than 60,000,000 single point touch |
|
Surface hardness |
7 Mohs |
|
Power（W） |
<1.5W, operating current <300mA |
|
Certification Regulation |
CE ISO9001:2000 |
|
|
Model |
size |
Border |
Touch Active Area |
Qutside Dimensions |
|
Thickness |
Height |
width |
diagonal |
height |
width |
|
|
|
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
|
IRTS-19S |
19 |
9.8 |
339 |
414 |
303 |
378 |
484.45 |
|
IRTS-21S |
21 |
9.8 |
311 |
413 |
306 |
408 |
510 |
|
IRTS-22S |
22 |
9.8 |
362 |
540 |
298 |
476 |
546.62 |
|
IRTS-24S |
24 |
9.8 |
416 |
592 |
324 |
518.4 |
611.3 |
|
IRTS-27S |
27 |
9.8 |
408 |
669 |
336 |
597 |
685.1 |
|
|
|
|
|
M Series |
|
Resolution |
4096*4096 |
|
Scan rate（scans/s） |
50scans/s |
|
Transmittance |
>95 last can to 100% |
|
Touch the smallest body |
>5mm |
|
Response speed |
﹥16ms |
|
Durability |
Bear more than more than 60,000,000 single point touch |
|
Surface hardness |
7 Mohs |
|
Power（W） |
<1.5W, operating current <300mA |
|
Certification Regulation |
CE ISO9001:2000 |
|
|
Model |
size |
Border |
Touch Active Area |
Qutside Dimensions |
|
Thickness |
Height |
width |
diagonal |
height |
width |
|
|
|
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
|
IRTS-30M |
30 |
11.6 |
406 |
646 |
353 |
594 |
703 |
|
IRTS-32M |
32 |
11.6 |
460 |
766 |
396 |
702 |
809 |
|
IRTS-42M |
42 |
11.6 |
593 |
540 |
298 |
476 |
546.62 |
|
IRTS-46M |
46 |
11.6 |
643.7 |
1089.7 |
577.7 |
1023.7 |
1175.5 |
|
IRTS-52M |
52 |
11.6 |
724 |
1228 |
654 |
1158 |
1330 |
|
IRTS-57M |
57 |
11.6 |
773 |
1322 |
707 |
1256 |
1441 |
|
|
|
|
|
|
L Series |
|
Resolution |
4096*4096 |
|
Scan rate（scans/s） |
50scans/s |
|
Transmittance |
>95，last can to 100% |
|
Touch the smallest body |
>5mm |
|
Response speed |
>16ms |
|
Durability |
Bear more than more than 60,000,000 single point touch |
|
Surface hardness |
7 Mohs |
|
Power（W） |
<1.5W, operating current <300mA |
|
Certification Regulation |
CE ISO9001:2000 |
|
|
Model |
size |
Border |
Touch Active Area |
Qutside Dimensions |
|
Thickness |
Height |
width |
diagonal |
height |
width |
|
|
(SIZE) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
|
IRTS-61L |
61 |
11.6 |
1021 |
1331 |
929 |
1239 |
1548.6 |
|
IRTS-65L |
65 |
11.6 |
1077 |
1412 |
1005 |
1034 |
1675 |
|
IRTS-84L |
84 |
11.6 |
1380 |
1806 |
1280 |
1706 |
2032.8 |
|
IRTS-100L |
100 |
11.6 |
1596 |
2104 |
1524 |
2032 |
2540 |
|
IRTS-103L |
103 |
11.6 |
1349 |
2341 |
1277 |
2269 |
2603.7 |
Prices
17inch single touch 40USD/pc MOQ 200pcs. sample 100USD/pc.
17inch multi touch 50USD/pc MOQ 200pcs, sample 150USD/pc.
42inch multi touch 400USD/pc MOQ 100pcs, sample 800USD/pc.
Price for other size please ask us.
Windows, XP Vista Win7 supported. Linux supported.
|
3.5, 4.3, 5.6 and 7 inch touch screens find here:
http://www.quickembed.com/Tools/Shop/ARM/Index.html
Online Order Now! Global Shipping in 2 days!
We accept online order and ship globally, our online order system will tell shipping fee according to your address, and automaticly generate PI Invoice to you.
Please send email to us if you have any question for this product, or want product document in more detail, or question for order or payment or shipping. Contact information is at the bottom of the page.
Sample price is announced hereby above. Ask for quotation when order quantity > 3pcs.
Parts of product, like core module, SBC, stamp, daughter card, single board(without LCD), motherboard, baseboard, LCD, sell seperately, email us for quatation.
find gps,gprs,wifi,camera etc in modules and bluetooth,485,can etc in accessories, or enclosures, jlink v8, ulink, openjtag etc tools.
We are now offer Capacitive Touch Panel for all of our ARM platforms.
Product Warranty and Technical Support.
