Price is for MOQ 500 pcs price. Sampling fee is 29USD/pc.
Spec:
LCD sample type: AT070TN83
LCD size: 7inch
Material: ABS+PMMA
Color: Black, Silver gray, white
Structure: SD card(MS/MMC/SM/SD), Speaker; power; DC IN
USB/MINI USB; RS232 etc
Size approximate
Inner size(mm):165.5(L) x 104.2(W) x 26.0(H)
Outer size(mm):215.0(L) x 154.0(W) x 34.0(H)
Weight: 55g
Here these products are provided AS IT IS, they serve for holding the LCD and board, just for demo purpose, they are not 100% fit with interface position and fixing position with our dev kit board. you can find good idea of using these cases for your purpose. They can be fixed on wall, on desktop etc.
type 1, 2, 3 are for desktop and have comparatively smaller height and space, need more work to put board in, should remove ethernet, usb etc from board. we recommend type 1.
type 4,5 are for wall mount and have bigger height and space, can put board and modules in easily. we recommend type 5.
Here is how to DIY and assembly.
If you are going to make it a product after successful demo, we can design one for you.
Refer to our case design service.
More Type
Type 1.
Only black color available currently, send email to us for stock information if you want white color.
Type 2.
Type 3.
Type 4
Size:236*189*37 (mm)
LCD viewer part: 156*94 (mm)
Type 5.
Size 250*160*42mm
Type5.1
Front Size: 285x195x30mm
Back Size: 250x160x22mm
Type5.2
Type5.3
Type5.4
Size: 255X165X28 (this type also provide 5.6inch option)
Type 6
Size: 178X160X100mm
Type 7, for 3.5inch
Type 8, for 3.5inch
175x112mm
Type MINI2440/MINI6410 7inch case
plastic box 49usd
aluminum box 69usd
We have more cases for 8inch 12inch 15inch size etc. please ask us for details.
Here are some samples:
http://www.quickembed.com/Tools/Shop/ARM/200912/59.html
http://www.quickembed.com/Tools/Shop/Solution/201004/90.html
