high performance connected PND, it is a GPS navigator with fashionable design, including all popular features as you expect and as it should, like real-time navigation, multimedia functionalities, etc.
Yet, it is far more than a navigation device. Inside there is also a built-in smart phone. it supports GSM communication like hand-free phone calls, short messages and so on.
More than that, an internal dial-up network and TCP/IP protocal provides a wireless access to internet so that internet surfing, email client, instant messanger, and all other features you enjoy with your lap-top is now available with an amazing information terminal.
Key features included,
High definition LCD 4.3" TFT with touch penal
Bluetooth support
High performance GPS receiver
SD card support
Multi-language support
Media Player
Dual-band GSM communication
GPRS dial-up network support
Specification
| Item |
Features |
| System |
|
| CPU |
Centrality® Atlas™-III AT642D 396MHz |
| Frequencies |
396 MHz (ARM core), 248 MHz (DSP core), 134 MHz (system), 124 MHz (memory) and 62 MHz (IO) |
| SDRAM |
256 MB NAND |
| OS |
WindowsCE.NET 5.0 core |
| Functions |
|
| GPS |
|
| media_border_left |
L1, 1575.42 MHz |
| Sensitivity |
-159 dBm |
| Channels |
32 |
| Accuracy |
| Position |
<10 meters |
| Velocity |
0.1m/s |
| Time |
0.01s to GPS time | |
| TTFF (Open sky) |
| Reacquisition |
0.1 sec, average |
| Hot start |
2 sec, average |
| Warm Start |
38 sec, average |
| Cold Start |
60 sec, average | |
| Antenna |
Embedded antenna and optional external antenna connection |
| External Antenna Connector |
MMCX |
| Dormancy / Awaken Key |
| GSM Connection(Dualband: 900/1800Mhz or 850/1900Mhz |
| Multimedia Player |
| Audio Format |
MP3 (up to 44 KHz), WMA 9(up to 44 KHz), WAV |
| Video Format |
MPEG-1, MPEG-4, AVI, ASF, 3GP, WMV,Divx |
| Text View |
| Format |
TXT, Office |
| Text browse |
Support TXT/Excel/Word/PPT |
| Display |
|
| Screen size |
4.3” diagonal |
| Resolution |
480 x 272 Dots |
| Display type |
Digital TFT LCD with 4-wire resistive touch panel |
| Brightness |
200 lumen |
| Indication light |
Blue LED |
| BlueTooth； Handfree |
| Game Playing(support SW download) |
| Audio |
| Integrated speaker |
| Stereo headphone jack |
| Web Interviewing (GPRS Class 10) |
| （Support MSN/ IE/Weather Report/Train Schedule/Stocks/Exchange rate/Online translation） |
| User Interface |
| Buttons |
On/Off (power), Sleep (on/off) |
| LEDs |
AC/DC Charging, Battery status |
Standard SD
(secure digital)
card slot |
Up to 4 GB SD card |
| USB |
Mini USB full speed |
| Stereo headphone jack |
3.5 mm |
| Reset key |
|
| Power Consumption |
| Consumption (typical) |
550 mA @ 4.2V (active, mute), 15mA @ 4.2V (sleep) |
| Handheld mode |
5V @ 1.2A (via AC adapter) or 3.7V (via 1,449 mAh lithium polymer battery) |
| Battery |
1400mAh |
| Warning System(Support EDOG etc.) |
| Physical dimension |
Main Unit
Dimensions |
130mm(l)x83mm(w)x17mm(t) |
| Main Unit Weight |
175g | More choice:
